GI Earthing Electrode (Strip in Pipe)
GI Earthing Electrode (Strip in Pipe) is a robust grounding solution designed for safe and effective electrical earthing. It consists of a galvanized iron (GI) outer pipe with a flat GI strip placed inside. This design enhances conductivity, corrosion resistance, and long-term performance, making it ideal for industrial and commercial earthing applications.
Product Description
| Product Model | Diameter of Electrode (mm) | Length of Electrode (meter) | Connection Terminal (mm) | Inner Strip Size (mm) |
|---|---|---|---|---|
| ADAS/GIEE/48 | 48 | 1, 2 & 3 | 32x6x100 | 25×3 |
| ADAS/GIEE/58 | 58 | 1, 2 & 3 | 40x6x100 | 25×3 |
| ADAS/GIEE/76 | 76 | 1, 2 & 3 | 50x6x100 | 25×6 |
| ADAS/GIEE/88 | 88 | 1, 2 & 3 | 50x6x100 | 25×6 |
The strip-in-pipe configuration provides superior conductivity and corrosion resistance, ensuring a long operational life even in challenging soil conditions. It is easy to install, maintenance-free, and ideal for residential, commercial, and industrial applications where consistent earthing performance is critical.
Trusted for its durability and performance, this electrode complies with IS 3043 and other standard electrical safety norms.
Key Features:
- High Conductivity: GI strip increases surface area for efficient fault current dissipation.
- Corrosion Resistance: Hot-dip galvanized pipe provides protection against rust and soil corrosion.
- IS 3043 Compliant: Manufactured as per Indian standards to ensure electrical safety and reliability.
- Easy Installation: Lightweight and versatile design allows for quick installation in various soil types.
- Maintenance-Free: Ensures long-term performance with minimal upkeep.
- Versatile Applications: Ideal for use in residential, industrial, and commercial grounding systems.
Review GI Earthing Electrode (Strip in Pipe).
